Stainless Steel Marine Marine Keyboard Gasket Sealed With 107 Rugged Keys

Certification
China Shenzhen PAC Technology Co., Ltd certification
China Shenzhen PAC Technology Co., Ltd certification
I got the keyboards. We are very pleased with quality from PAC TECHNOLOGY CO., LTD. They are made perfectly. We will order more.

—— Juan

It is the right choice to buy your professional keyboards! Thank you!

—— Marks

The trackballs have been received last week, and we have tested them. The result is positive. The trackballs fit our project perfectly! You are on our supplier list and we will buy more soon.

—— Carol

Thanks for your patience in communication, it is really nice working with you.

—— Lee

I'm Online Chat Now

Stainless Steel Marine Marine Keyboard Gasket Sealed With 107 Rugged Keys

Stainless Steel Marine Marine Keyboard Gasket Sealed With 107 Rugged Keys
Stainless Steel Marine Marine Keyboard Gasket Sealed With 107 Rugged Keys Stainless Steel Marine Marine Keyboard Gasket Sealed With 107 Rugged Keys

Large Image :  Stainless Steel Marine Marine Keyboard Gasket Sealed With 107 Rugged Keys

Product Details:

Place of Origin: Made in China
Brand Name: PAC
Certification: CE, FCC, ROHS
Model Number: P-F478TP-BT

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: Negotiation
Packaging Details: Inner box plus outer carton
Delivery Time: 1-2 weeks
Payment Terms: TT, PayPal, Western Union
Supply Ability: 3000pcs per month
Detailed Product Description
Gasket Sealed: Yes Material: Black Stainless Steel
Touchpad: Yes Keys: 107 Rugged Keys
Trackball Optional: 107 Application: Marine
High Light:

light up keyboard

,

backlit mechanical keyboard

Gasket Sealed Black Stainless Steel Marine Keyboard With 107 Rugged Keys


Marine Keyboard Description:
Compact format IP67 dynamic water proof vandal proof stainless steel industrial keyboard with
durable polymer keys and IP68 dynamic washable 38.0mm stainless steel optical trackball module with 800 DPI
resolutions for fast and accurate coursor position, with fully sealed and ruggedized industrial PCB with carbon-on-gold key
switch technology with long stroke (2.0mm) with extremely good tactile feeling for fast and accurate data input without
any noise, functional keys F1, F2, F3...F10, F11, F12 are on the top line for easy operation. High quality durable black
titanium electroplated on the top stainless steel plate, 3 mouse buttons designed for right & left clicking and scrolling up
and down with ball rolling, strong durable polymer keys caps with laser technology for backlight out, with adjustable
backlight included, stainless steel top plate with sealing gasket and threaded bolts for top panel mounting solution.


Black Metal Keyboard Main Features:

  • 107 keys compact format vandal proof black stainless steel industrial keyboard
  • With sealed touchpad mouse
  • With extremely good tactile feeling for fast and accurate data input without any noise
  • Rear panel mount solution
  • Switch life: more than 5 million of operations
  • Actuation Force: <1N
  • OS: All windows, Linux, Unix, Mac OSX
  • USB or PS2 interface, plug and play, with external power supply
  • No external power supply necessary, keyboardport power sufficient
  • Supply Voltage: +5V DC +/-5%
  • Current Rating: appr. 20mA
  • Compact thickness
  • Protection Level: IP65(front panel)
  • Vandal resistant IK09
  • MTBF >50000H
  • MTTR <30min
  • Dimension: 400.0mm x 124.0mm (front panel) (drawing download: P-F478TP (BT) drawing.pdf)
  • Weight: 2.5kg
  • CE, FCC, ROHS
  • P-F478TP-BT data sheet download: P-F478TP-BT data sheet.pdf

Optinal Trackball Features:

  • Removable panel mount 38mm quadrature optical trackball mouse module for fast and accurate movment
  • Black color or stainless steel
  • The trackball is approval with CE, FCC, ROHS standards.
  • Other diameter balls, like 50.mm or 25.mm is available
  • The mechanical trackball and the laser trackball is optional
  • Carrier plate: Brushed stainless steel
  • Ball material: heavy stainless steel ball or light harden resin ball
  • Push button switches use gold plated contact material
  • Interface: USB, PS2, or quadrature
  • No external power supply necessary, keyboardport power sufficient

Optinal Trackball Data Sheet:

Color: black
Front panel material: metal
keys material: metal
Power supply: DC5V±5%
Working current: <150mA
Interface: USB, PS2
Operation force: <1N
Durability: ≥5 Million
Trackball Size: 38.mm
Operation temperature: -10℃ ~ 55℃
Storage temperature: -30℃ ~ 85℃
Compatible with operation systems: All Windows, Linux, Ubuntu, Android systems etc.


Marine Keyboard FAQs:
Q1. Where to buy the industrial marine keyboard?
Please email or call us with your detailed request, and then we will make the professional suggestions.
Customers can buy directly from us or from our distributors.

Q2. How to make the marine keyboard delivery?
For the small quantity trackballs, usually delivery by express courier like DHL, UPS, FedEx with door-to-door service
For the big quantity trackballs, usually by LCL sea shipping or air shipping.

Q3. What is the warranty for the marine keyboard?
Standard 1-year, but the trackball warranty can be exteneded with extra cost.

Q4. Is it possible to make the customs marine keyboard size?
Yes, it is possible, please email us your detailed trackball request.

Q5. What is the term of the quotation please?
Our quotation is standard by EXW.
We can help our customers to arrange the shipping with prepaid shipping.
Alternatively the customers can aslo use their own express count or their appointed shipping agent for freight collect.

Q6. What is the lead-time for the marine keyboard?
The lead-time is as soon as possible 1 week for the small quantity under 10 units.
Sometimes we have the small stock for the samples.
The lead-time is as soon as possible 2 weeks for the quantity around 50 units.
